Epoxy Concrete Patch Repair Mortar- Rapid Cure

Description

Epoxy Concrete Patch Repair Mortar – Rapid Cure

CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure is a high strength, trowel applied, three component Epoxy resin-based mortar designed for rapid and permanent repairs to concrete and masonry surfaces. CPR 716 is a blend of Epoxy resin, Polyamine curing agent, graded siliceous aggregates and colour pigments. The mixed material is applied to a suitably prepared and primed surface, and quickly cures to form a durable, abrasion and chemical resistant repair.

Typical Properties

Pre-packed units – ready to use
Fast curing characteristics
Impact and abrasion resistant
Frost resistant and impervious to water
Excellent mechanical properties
Unaffected by a wide range of acids, and industrial chemicals
Negligible shrinkage
High bond strength
Cures under damp, cool conditions

Directions for Use

Surface Preparation

Remove all laitance, spalled concrete, grease, oil, dust and other contaminants by scabbling or bush hammering to provide a sound, clean, substrate.
Any exposed reinforcing steel shall be fully exposed by cutting out around its full circumference, and cleaned by abrading or grit blasting to remove rust, scale, etc.
Metal substrates shall be degreased and grit blasted to Sa 2.5 Swedish Standard, or power wire brushed.

Priming

The prepared concrete surface shall be primed by the application of CPR 404 – Rapid Cure Primer for Concrete Repair Mortars which should be brushed well in.
A coat of primer should also be applied to any exposed rebars.

Mixing

CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure is supplied as a three component pack.
Each component is pre-weighed and ready to mix.
Pour the contents of the CURING AGENT container into the BASE container and mix thoroughly by spatula or low speed drill/stirrer.
The mixed resins shall be poured into a forced action mixing vessel, (Creteangle bucket or similar), and the AGGREGATE added steadily whilst the mixer is in motion.
Mix for 2-3 minutes until a uniform consistency has been achieved.

Application

CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure shall be applied whilst the primer is still ‘tacky’, which is usually between 10 and 60 minutes after primer application.
Apply the Patch Repair Mortar by tamping and trowelling to ensure good compaction and a tight finish.
The material should not be feather edged.
Maximum thickness in horizontal applications is 20mm.
For deeper sections re-prime and re-apply additional CPR 716.
For vertical applications the material may be built up in layers not exceeding 6mm.

Equipment Cleaning

Clean equipment with CPR 201 – Tool Clean Solvent prior to curing of the mortar.

Curing

CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure will have hardened sufficiently after 5-6 hours @ 15-20°C to allow overcoating or full trafficking.
Longer periods of cure will be necessary at lower temperatures.
Full mechanical and chemical resistant properties will be achieved following 3 days cure @ 20°C.

Storage and Shelf Life

Store in dry conditions at temperatures between 10°C and 25°C.
Avoid low temperature storage prior to use of the material.
Do not expose to freezing conditions.
CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure has a minimum shelf life of 12 months when stored in original, unopened containers in accordance with manufacturer’s instructions.

Packaging

CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure is supplied in 7.5kg and 15kg packs

Coverage

A 7.5kg pack yields 3.75 litres of Epoxy mortar, sufficient for 0.75m² at 5mm thickness.
A 15kg pack yields 7.50 litres of Epoxy mortar, sufficient for 1.5m² at 5mm thickness.

Technical Data

Colour: Grey (BS4800 or RAL colours available on request)
Density: 2010kg/m³
Pot Life: 30 minutes @ 20°C
Adhesion to concrete: >3.9MPa (concrete failure)
Compressive Strength: 85MPa
Tensile Strength: 13MPa
Taber abrasion resistance: 40mg weight loss (CS17 wheels; 1kg loads, 1000 cycles)
Thermal Coefficient of Linear Expansion: 3 x 10–5 cm/cm/°C
Maximum Service Temperature: 70°C continuous
Chemical resistance: Excellent resistance to 20% hydrochloric acid, 20% sulphuric acid, 10% citric acid, 25% sodium hydroxide, diesel and petrol.
Very good resistance to 10% lactic acid, 50% phosphoric acid, 10% nitric acid and 5% acetic acid.
Good resistance to many common industrial chemicals.
Please consult our Technical Team for specific advice.

Limitations

Do not apply to wet or uncured concrete surfaces.
Do not apply at temperatures of 3°C or less

Health and Safety

Wear gloves and goggles.
Wash off splashes immediately with soap and water.
Any eye contamination must be rapidly irrigated with copious amounts of water, and immediate medical attention sought.
Please refer to Material Safety Data Sheet for additional information.
CPR 716 – Epoxy Concrete Patch Repair Mortar- Rapid Cure shall be applied strictly in accordance with the manufacturer’s instructions.
For specific advice regarding any aspect of this product please consult our Technical Team.

Legal Notice

Whilst all reasonable care is taken in compiling technical data on the Company’s products, all recommendations or suggestions regarding the use of such products are made without guarantee, since the conditions of use are beyond the control of the Company.

It is the customer’s responsibility to satisfy himself that each product is fit for the purpose for which he intends to use it, that the actual conditions of use are suitable and that in the light of our continual research and development program the information relating to each product has not been superseded.
